Straight Deck Pintle Series SD.7K
Brand: Canada Trailers
Component
Details
GVWR
7,560 lbs
Axles
(2) 3,500 lbs Axles w/Easy Lube Spindles
Suspension
Slipper Spring Suspension
Tires
ST205/75R15 LRC Radial
Brakes
Electric on Both Axles
Coupler
Adjustable 2-5/16" Coupler or 3" Lunette Eye
Jack
12,000 lbs Drop Leg Jack
Deck Height
32"
Frame
Light Weight, Rigid Frame
Crossmembers
Every 16"
Ramps
7' Ramps, Stowed Under Deck
Floor
Pressure Treated Wood
Tongue Length
62"
Tie Downs
Stake Pockets & Rub Rails
Side Steps
On Both Sides
Spare Tire Mount
Optional - Tongue Mount Only
Lights
Sealed Beam, L.E.D.
Electrical
Sealed Harness System
Plug
7-Way RV Plug
Finish
Powder Coat + Scorpion Stone Guard
Number
Details
SD16-7K
Size: 102" X 192"; Weight: 2,855 lbs; Payload: 4,675 lbs
SD18-7K
Size: 102" X 216"; Weight: 3,015 lbs; Payload: 4,545 lbs
SD20-7K
Size: 102" X 240"; Weight: 3,208 lbs; Payload: 4,352 lbs
