The KL1402 Front-End Loader fits KIOTI HX1302 and HX1402 tractors. Specifications may vary with tractor model, front axle configurations, tire size option and type of attachment and are subject to change without notification.
Today’s hours /
8:00AM – 4:30PM
What are you looking for?
KL1402 Front End Loader
Brand: Kioti
Front End Loaders
Dirt, gravel, manure, logs, bags of fertilizer, a giant stump, chicken feed, a pile of fence posts… If it’s on your land and it needs to be scooped, lifted, pushed around or carried somewhere, a KIOTI front end loader will get it done.
Component
Details
Models
KL1402
Compatibility
Lift Height Max Pivot Pin
159.90 in (4,062 mm)
Lift Height Max Pivot Pin
121 in (3,704 mm)
Clearance Dumped
122 in (3,100 mm)
Reach at Ground
100.40 in (2,550 mm)
Digging Depth
8.40 in (214 mm)
Bucket Capcity Heaped
Breakout Force at Pivot Pin
7,936 lb (3,600 kg)
Bucket Depth
Bucket Weight
640 lb (290 kg)
Bucket Size
Dump Angle Max
45 °
Length
Bucket Cylinder
3.1 x 1.6 x 18.5
Lift Capacity to Full Height
5,533 lb (2,510 kg)
Bucket Capacity Rated
26.50 ft³ (0.75 m³)
Rollback Angle Max
