Engine
Type: Diesel 4-cylinder, Intercooled Turbo
Model: Yanmar 4TN86CHT
Gross Power Rating: 74 hp
Displacement: 2.1 L
Torque, Peak: 195 ft-lb
Cooling System: Belt-driven fan and anti-freeze filled radiator cooling system
Intake Air Cleaner: Dual-stage
Emission Controls: Meets all U.S. EPA Tier 4 final standards
Operating Weight
Loader Arms: Vertical
Operating Weight (Open ROPS Base): 9,610 lbs
Operating Weight (AWC Cab Base): 9,950 lbs
Ground Pressure at Operating Weight: 5.1 psi
Rated Operating Capacity (35% of tipping load): 2,900 lbs
Tipping Load: 8,286 lbs
Travel Speed, Maximum: 8 mph
Undercarriage
Track Width: 15.7 in.
Length of Track on Ground: 60 in.
Ground Contact Area: 1,884 in.²
Drive System: Two hydrostatic direct drive sprockets controlled by single joystick
Undercarriage Suspension: Two independent torsion axles per undercarriage
Auxiliary Hydraulic System
Pump Capacity, Low/High: 24.7 / 34.3 gpm
Max System Pressure, Low / High: 3,480 / 3,771 psi
Controls: Intermittent via joystick button or continuous via console switch
Couplers: Flat Faced Couplers: 1/2 in.
Cooling System: High efficiency side-by-side radiator and oil cooler
Operator Station
Cab: ROPS or All-Weather Cab with curved glass door
Seat: Mechanical suspension seat with 2-in. seat belt
Controls: Electronic joystick controls with ISO or H pattern settings, adjustable operator profiles and speeds
Engine Speed: Standard hand dial operation with foot pedal optional
7-in. Color Machine Display: Fuel, tachometer, engine temp, hour meter, battery, trip meter, hydraulic temperature, water temperature, multiple languages
ROPS: ISO 3471
Restraint: ISO 6683, SAE J2292, Cal OSHA 1596
FOPS: ISO 3449 Level 1 (Level 2 optional), emergency roof exit
Illumination: 2 – Forward-facing LED lights, 2 – Rear-facing LED lights
Standard Features: Mechanical suspension seat, fixed joystick controls, 7-in. color display, roof panel, rear window, cupholder, two speed, standard flow
Optional Features: All Weather Cab, heat & A/C, adjustable joystick controls, foot throttle, phone holder, radio with Bluetooth and USB, roof insulation, high flow, 3 in. seat belt, air ride seat, rotating magnetic beacon, LED side lights, backup camera, SmartAssist Remote telematics, 1/2 in. polycarbonate door, Hyd Q/A, attachment control kit, dual direction bucket positioning, return to position, ride control.
